Tracing is an important approach for controlling and monitoring the experience of users, it allows us to gather more information about an integration’s performance.

Camel K has been providing support for distributed tracing using OpenTracing since long time. At the beginning of 2022, the CNCF announced that they were archiving the OpenTracing project in favor of the OpenTelemetry project. OpenTelemetry is the latest solution created by merging OpenTracing and OpenCensus. As a result, we decided in Camel K 1.12 to introduce the telemetry trait based on OpenTelemetry. At the same time we decided to deprecate the tracing trait based on OpenTracing.

I’ll walk you through the configurations needed to support Distributed tracing for your Camel integrations in this blog post.

Distributed Tracing tools

OpenTelemetry defines the OpenTelemetry Protocol (OTLP) that allows any Distributed Tracing tool that provides an OTLP compatible collector API to be used. While OpenTelemetry is still CNCF incubating project, it has become an industry-standard and is now natively supported by many Distributed Tracings tools.

The telemetry trait has been tested on Jaeger (v1.35+), OpenTelemetry Collector and Grafana Tempo at the time of writing this blog post.

We will be using Jaeger for this blog post manipulations.

Camel K

The telemetry trait is available starting from Camel K version 1.12, so you should first check your kamel client version

$ kamel version
Camel K Client 1.12.0

To install the Camel K operator just execute

$ kamel install

Check if the Camel K operator is available

$ kubectl get pods -l name=camel-k-operator
NAME                                READY   STATUS    RESTARTS   AGE
camel-k-operator-5b897ddcdd-4qwqb   1/1     Running   0          50s

For more information see the documentation

Install Jaeger

For this installation, you should first ensure that ingress is available on your kubernetes. If you are working on minikube minikube addons enable ingress should be enough.

If Jaeger is not already available on your kubernetes instance, an easy way to install it on a kubernetes is to install the Jaeger operator (see https://www.jaegertracing.io/docs).

In short, to install the Jaeger operator you should:

  • Install cert-manager if it is not installed as it is required
 # The cert manager is a prerequisite to the Jaeger operator (see https://cert-manager.io/docs/installation/)
$ kubectl apply -f https://github.com/cert-manager/cert-manager/releases/download/v1.10.1/cert-manager.yaml

Wait 1 or 2 minutes, we want to ensure the cert-manager has had enough time to be fully deployed

 # see https://www.jaegertracing.io/docs/1.42/operator/#installing-the-operator-on-kubernetes
$ kubectl create namespace observability
$ kubectl create -f https://github.com/jaegertracing/jaeger-operator/releases/download/v1.42.0/jaeger-operator.yaml -n observability

Check if Jaeger-operator is available:

$ kubectl get deployment jaeger-operator -n observability

NAME              DESIRED   CURRENT   UP-TO-DATE   AVAILABLE   AGE
jaeger-operator   1         1         1            1           48s

To use Jaeger, you can install the AllInOne image:

$ kubectl apply -f - << EOF
apiVersion: jaegertracing.io/v1
kind: Jaeger
metadata:
  name: instance
EOF

Check the presence of the Jaeger instance:

$ kubectl get jaeger
NAME       STATUS    VERSION   STRATEGY   STORAGE   AGE
instance   Running   1.42.0    allinone   memory    8s

Run some Camel K Integrations with Telemetry trait

Now that we have Jaeger available on the Kubernetes cluster, the next step is to run some integrations in a Kubernetes cluster where Camel K is installed. You can find the source code in the Camel K example GitHub repository.

We will be creating two integration routes as the distributed services:

  • Inventory which is also a rest service in charge of product’s inventory management

InventoryService.java

import org.apache.camel.builder.RouteBuilder;
import org.apache.camel.model.rest.RestBindingMode;
import org.apache.camel.component.jackson.JacksonDataFormat;
import java.text.SimpleDateFormat;
import org.apache.camel.Exchange;
import java.util.Date;
import java.util.Map;


public class InventoryService extends RouteBuilder {

    @Override
    public void configure() throws Exception {
        restConfiguration()
            .enableCORS(true)
            .bindingMode(RestBindingMode.json);

        rest()
            .post("/notify/order/place")
                .to("direct:notify");

        JacksonDataFormat invDataFormat = new JacksonDataFormat();
        invDataFormat.setUnmarshalType(InventoryNotification.class);

        from("direct:notify")
            .log("notifyorder--> ${body}")
            .setHeader(Exchange.CONTENT_TYPE, constant("application/json"))
            .bean(InventoryNotification.class, "getInventoryNotification(${body['orderId']},${body['itemId']},${body['quantity']} )")
            .marshal(invDataFormat)
            .log("Inventory Notified ${body}")
            .convertBodyTo(String.class)
        ;
    }

    private static class InventoryNotification {
        private Integer orderId;
        private Integer itemId;
        private Integer quantity;
        private String department;
        private Date datetime;

        public static InventoryNotification getInventoryNotification(Integer orderId, Integer itemId, Integer quantity ){
            InventoryNotification invenNotification  = new InventoryNotification();
            invenNotification.setOrderId(orderId);
            invenNotification.setItemId(itemId);
            invenNotification.setQuantity(quantity);
            invenNotification.setDepartment("inventory");
            SimpleDateFormat formatter= new SimpleDateFormat("yyyy-MM-dd 'at' HH:mm:ss z");
            invenNotification.setDatetime(new Date(System.currentTimeMillis()));
            return invenNotification;
        }


        public void setOrderId(Integer orderId){
            this.orderId=orderId;
        }
        public void setItemId(Integer itemId){
            this.itemId=itemId;
        }
        public void setQuantity(Integer quantity){
            this.quantity=quantity;
        }
        public Integer getOrderId(){
            return this.orderId;
        }
        public Integer getItemId(){
            return this.itemId;
        }
        public Integer getQuantity(){
            return this.quantity;
        }
        public String getDepartment() {
            return department;
        }
        public void setDepartment(String department) {
            this.department = department;
        }
        public Date getDatetime() {
            return datetime;
        }
        public void setDatetime(Date datetime) {
            this.datetime = datetime;
        }
    }
}
  • Order which is a rest service called by a user to place an order for a product, that will then notify the Inventory service

OrderService.java

import java.util.HashMap;
import org.apache.camel.Processor;
import org.apache.camel.builder.RouteBuilder;
import org.apache.camel.model.rest.RestBindingMode;
import org.apache.camel.Exchange;
import org.apache.camel.component.jackson.JacksonDataFormat;
import org.apache.camel.processor.aggregate.GroupedBodyAggregationStrategy;

public class OrderService extends RouteBuilder {

    @Override
    public void configure() throws Exception {

        restConfiguration()
            .enableCORS(true)
            .bindingMode(RestBindingMode.json);

        rest()
            .post("/place")
                .to("direct:placeorder");

        JacksonDataFormat jacksonDataFormat = new JacksonDataFormat();
        jacksonDataFormat.setUnmarshalType(Order.class);

        from("direct:placeorder")
            .log("-----IN ${headers}")
            .marshal(jacksonDataFormat)
            .log("inputBody --> ${body}")
            .to("http://inventory/notify/order?bridgeEndpoint=true")
            .removeHeaders("*")
            .log("responseBody from inventory --> ${body}")
            .setHeader(Exchange.CONTENT_TYPE, constant("application/json"))
            .setBody(simple("{\"inventory\":${body}}"))
            .unmarshal().json()
        ;
    }

    private static class Order implements java.io.Serializable{
        private static final long serialVersionUID = 1L;
        private Integer orderId;
        private Integer itemId;
        private Integer quantity;

        private String orderItemName;
        private Integer price;

        public void setOrderId(Integer orderId){
            this.orderId=orderId;
        }
        public void setItemId(Integer itemId){
            this.itemId=itemId;
        }
        public void setQuantity(Integer quantity){
            this.quantity=quantity;
        }
        public void setOrderItemName(String orderItemName){
            this.orderItemName=orderItemName;
        }
        public void setPrice(Integer price){
            this.price=price;
        }
        public Integer getOrderId(){
            return this.orderId;
        }
        public Integer getItemId(){
            return this.itemId;
        }
        public Integer getQuantity(){
            return this.quantity;
        }
        public String getOrderItemName(){
            return this.orderItemName;
        }
        public Integer getPrice(){
            return this.price;
        }

    }
}

Let’s run our camel integrations:

  • the Inventory integration
$ kamel run InventoryService.java --name inventory \
   -d camel-jackson \
   -t telemetry.enabled=true \
   -t telemetry.sampler=on \
   -t ingress.enabled=true \
   -t ingress.host=inventory.local
Integration "inventory" created
  • the Order integration
$ kamel run OrderService.java --name order \
   -d camel-jackson \
   -t telemetry.enabled=true \
   -t telemetry.sampler=on \
   -t telemetry.service-name=external-order \
   -t ingress.enabled=true \
   -t ingress.host=order.local
Integration "order" created

This configuration will:

  • enable tracing for our integrations
  • sample all traces
  • send traces to OTLP API endpoint

We are also using inventory.local and order.local host in ingress for the rest services so make sure that your DNS pointing to your cluster for both hostnames. You can execute echo "$(minikube ip) order.local inventory.local" | sudo tee -a /etc/hosts if you are working on minikube.

As you can see we did not provide the OTLP API endpoint as Camel K automatically discovered the Jaeger OTLP API endpoint available in the namespace. For any other Distributed Tracing tool you will have to declare it through -t telemetry.endpoint=xxxx. The telemetry trait is expecting an OTLP trace endpoint.

Now that everything is up let’s make some traces!

Generate some integration traces

  1. Let’s place some order:
$ curl  http://order.local/place -d '{"orderId":1, "itemId":5, "quantity":1, "orderItemName":"best product", "price":99}' -H "Content-Type: application/json"
{"inventory":"{\"orderId\":1,\"itemId\":5,\"quantity\":1,\"department\":\"inventory\",\"datetime\":1678293274691}"}

If the call went well, you should have this response indicating that the inventory service has been called.

In Jaeger’s interface we should see the call with the spans referencing to the rest services and camel components.

Jaeger full trace

  1. Now, we will stop collecting the traces for the Order integration:
kamel run OrderService.java --name order \
   -d camel-jackson \
   -t ingress.enabled=true \
   -t ingress.host=order.local
Integration "order" updated

If we create another order:

$ curl  http://order.local/place -d '{"orderId":2, "itemId":18, "quantity":1, "orderItemName":"another product", "price":5}' -H "Content-Type: application/json"
{"inventory":"{\"orderId\":2,\"itemId\":18,\"quantity\":1,\"department\":\"inventory\",\"datetime\":1678293771675}"}

As we can see in Jaeger’s interface looking for the inventory traces the call will only show the spans for inventory and no longer the order parent spans.

Jaeger inventory trace

As you can see, it is quite easy to improve the observability of your integrations using the new telemetry trait.

From tracing to telemetry

We are encouraging migration from the tracing trait to the telemetry trait.

To give you some inputs on your migration, I will show you how to collect and compare the traces using both traits.

Let’s deploy two different Order integrations to compare the traces generated :

  • stop collecting the traces from Inventory integration
kamel run InventoryService.java --name inventory \
   -d camel-jackson
Integration "inventory" updated
  • update the Order integration using the telemetry trait
$ kamel run OrderService.java --name order \
   -d camel-jackson \
   -t telemetry.enabled=true \
   -t telemetry.sampler=on \
   -t telemetry.service-name=order-external-telemetry \
   -t ingress.enabled=true \
   -t ingress.host=order.local
Integration "order" updated
  • the Order integration using the tracing trait
$ kamel run OrderService.java --name order-tracing \
   -d camel-jackson \
   -t tracing.enabled=true \
   -t tracing.sampler-type=const \
   -t tracing.sampler-param=1 \
   -t tracing.service-name=order-external-tracing \
   -t ingress.enabled=true \
   -t ingress.host=order-tracing.local
Integration "order-tracing" created

Don’t forget to ensure the new order-tracing.local hostname is configured for your kubernetes cluster!

Let’s create the same orders with the two order services:

  • one with the order service using the new telemetry trait
$ curl  http://order.local/place -d '{"orderId":20, "itemId":5, "quantity":1, "orderItemName":"strange product", "price":10}' -H "Content-Type: application/json"
{"inventory":"{\"orderId\":20,\"itemId\":5,\"quantity\":1,\"department\":\"inventory\",\"datetime\":1678296117315}"}
  • another with the order services using the deprecated tracing trait
$ curl  http://order-tracing.local/place -d '{"orderId":21, "itemId":5, "quantity":1, "orderItemName":"strange product", "price":10}' -H "Content-Type: application/json"
{"inventory":"{\"orderId\":21,\"itemId\":5,\"quantity\":1,\"department\":\"inventory\",\"datetime\":1678296184049}"}

As you can see, going from the trancing to the telemetry is quite effortless. On the trace side, from one protocol to another you should expect some differences in your tracing:

Difference between OpenTracing and OpenTelemtry traces

Conclusion

This blog post showed how you can use the new telemetry trait and how to work with the Jaeger Distributed Tracing tool. We also took the time to see how you can migrate from the deprecated tracing trait to the telemetry trait.

If you have any feedback, ideas or find a new issue, please create a new issue report in GitHub!
